. To be installed mainly on the glass door (Swing: 180°)
. Auto locking
. Time delay
. To be opened when its power is cut off
. This is a product of SOCA and has been the most widely used product due to its proven high quality
. It can help decrease the burden on the power supply unit by reducing unnecessary power consumption during the standby state. This product generates only minor internal heat even when it is used for a long duration, so it has an excellent durability
. There is an input terminal for opening a door, which can be used after being connected to an exit S/W or an interphone.
. The closing delay time can be set simply by using the dip S/W.
. Special materials are used, which can help reduce the level of noise and the coefficient of friction, consequently providing a longer product life time.
Electric specification.
. Power : DC12V/ DC24V . Power consumption : 900mA when using DC12V / 300mA (While in the standby state) . Activation delay time : 0 sec/ 3 sec . Delay time in shifting to the standby state : 7sec . Door monitoring . Size : Main body face plate 200×32×40mm/ Amateur plate 90×26×2mm . Bolt : 16mm(Throw) x 15.5cm(Diameter)
※ Fail Safe (Opening when power is cutff) ※ Fail Secure (Closing when power is cut off)
